SJ8477SS RBC Needle Bearing
SJ 8477 SS
RBC BEARINGS SJ 8477 SS
Needle Bearing Roller Assembly with Outer Ring; 2-3/4" Bore; 3-1/2" Outside Diameter; 1-3/4" Width; Needle Roller Bearing; 2 Seals; No Self Aligning; Retainer; Single Row; No Separable; No Closed End; Relubricatable
Payment & Shipping Terms
| Minimum Order Quantity: | 1 pcs |
| Price: | Contact with Sales |
| Packaging Details: | SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS |
| Delivery Time: | 5-7 Days After payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000pcs/month |
Product Description
| Product Name | RBC Heavy Duty Pitchlign Needle Bearing - Double Sealed | ||
| Description | SJ8477SS - RBC Heavy Duty Pitchlign Needle Bearing - Double Sealed - 2.75" Bore x 3.5" OD x 1.75" Width | ||
| Type | Double Seal, Lips Mounted Outward | ||
| Style | Caged Needle Bearing, Sealed | ||
| Inch/Metric | Inch | ||
| Inner Diameter | 2.75" | ||
| Outer Diameter | 3.5" | ||
| Width | 1.75" | ||
| Outer Ring Width | 1.75" | ||
| Bearing Material | 52100 Bearing Quality Steel | ||
| Finish | Chrome Steel | ||
| Operating Temperature | -40 to 300 ºF | ||
| Enclosure | Sealed | ||
| Cage Material | Steel | ||
| Fillet Radius | 0.08" | ||
| Series | Pitchlign® | ||
| Seal Type | Sealed | ||
| Compatible Inner Ring | IR8477 | ||
| Bore Size (in) | 2.75 | ||
| Bore Size (mm) | 69.85 | ||
| Dynamic Load Rating (lbf) | 16300 | ||
| Dynamic Load Rating (N) | 72505.986 | ||
| Item Name | RBC Heavy Duty Pitchlign Needle Bearing - Double Sealed | ||
| Lubrication Type | Hole On Outer Ring | ||
| Material | 52100 Bearing Quality Steel | ||
| Operating Temperature (Max) ºC | 148.9 | ||
| Operating Temperature (Max) ºF | 300 | ||
| Operating Temperature (Min) ºC | -40 | ||
| Operating Temperature (Min) ºF | -40 | ||
| Outside Diameter (in) | 3.50 | ||
| Outside Diameter (mm) | 88.90 | ||
| Seal Material | Sealed | ||
| Static Load Rating (lbf) | 39600 | ||
| Static Load Rating (N) | 176149.512 | ||
| Weight (lb) | 1.4 | ||
| Bore Shape | Round | ||
| Fillet Radius/Chamfer (in) | 0.08 | ||
| Fillet Radius/Chamfer (mm) | 2.032 | ||
| Precision Rating | Not Rated | ||
| Speed (Max) (rpm) | 1400 | ||
| Total Width (in) | 1.750 | ||
| Total Width (mm) | 44.45 | ||
