HEIM REP4M6FS464 RBC Airframe Bearing

REP4M6FS464 - RBC Airframe Bearing - 0.2500" Bore x 0.9380" OD x 0.5930" Width,Male Double Row Ball Bearing Rod End, Cadmium Plated, Sealed
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Contact with Sales
Packaging Details: SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS
Delivery Time: 5-7 Days After payment
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 100000pcs/month

Product Description


Product Name     RBC Airframe Bearing - REP M Series
Description     REP4M6FS464 - RBC Airframe Bearing - 0.2500" Bore x 0.9380" OD x 0.5930" Width
Type     Male Double Row Ball Bearing Rod End, Cadmium Plated, Sealed
Style2     Ball Bearing
Inch/Metric     Inch
Inner Diameter     0.25"
Outer Diameter     0.938"
Width     0.593"
Thread Type     UNJF-3A
Inner Ring Width     0.593"
Outer Ring Width     0.438"
Tilt Angle     10º
Length To Center of Ball     1.875"
Bearing Material     52100 Bearing Quality Steel
Finish     Cadmium
Operating Temperature     Less Than 200 ºF
Enclosure     Sealed
Housing Material     52100 Bearing Quality Steel
Race Material     PTFE
Series     RBC®
Stud Type     Male (Outer Thread) Stud
Thread Direction     Right-Handed Thread
Thread Gender     Male (Outer Thread) Stud
Bore Size (in)     0.25
Bore Size (mm)     6.00
Industry Standards/Certifications     SAE-AS6039, MIL-PRF-81322
Inside Ring Width (in)     0.593
Inside Ring Width (mm)     15
Item Name     RBC Airframe Bearing - REP M Series
Lubrication Type     Prelubricated
Misalignment Angle º     10
Operating Temperature (Max) ºC     93.3
Operating Temperature (Max) ºF     200
Performance     Aircraft
Static Load Rating (lbf)     1720
Static Load Rating (N)     7651
Weight (lb)     0.1
Weight (kg)     0.05
Total Height (in)     2.344
Total Height (mm)     60
Bearing Type     Ball Bearing Rod End
Thread Length (in)     1.125
Thread Size     0.375-24
Center Line Length (in)     1.875
Ball Diameter (in)     0.593
Ball Diameter (mm)     15
Shaft Height (mm)     48
Head Width (mm)     11
Ball Material     52100 Alloy Steel
Head Diameter (in)     0.9380
Head Diameter (mm)     24
Insert Material     PTFE
Shaft Height (in)     1.875
Thread Length (mm)     29
Head Width (in)     0.438

Suzhou DSN Bearings Limited Advantages:

Suzhou DSN Bearings Limited. We have deal with the bearing import and export business more than 20 years.

The company sells NHBB bearings,KAYDON bearings,RBC bearings,INA bearings,MCGILL bearings,RBC bearings,NTN bearings,IKO bearings,KOYO bearings,SFERAX bearings,NMB bearings,NACHI bearings,BARDEN bearings,WINKEL bearings,C-FLEX bearings and other Europe and the United States High precision bearing products.

The main brands are as follows:German brands: MYONIC, GMN, GRW, FAG INA STIEBER NADELLA BARDEN STAR,American brand: NHBB KAYDON RBC MCGILL MRC C-FLEX BARDENJapanese brand: NSK NTN NACHI IJK NMB EZO IKO THK ASAHI KOYO FYHEuropean brand: SKF SNFA RHP SNR ADR RBF ZKL NKE WIB COOPER SFERAX and so on.




FAQs

A: We promise to bear the following responsibilities when defective products were found:

  • 1. 12 months warranty from the first day of receiving goods;
  • 2. Replacements would be sent with goods of your next order;
  • 3. Refund for defective products if customers require.

A: Yes, we provide ODM&OEM services to worldwide customers, we also customize OEM box and packing as your requirements.

A: MOQ is 10pcs for standardized products; for customized products, MOQ should be negotiated in advance. There is no MOQ for sample orders.

A: The lead time for sample orders is 3-5 days, for bulk orders is 5-15 days.

A: Yes we offer free samples to distributors and wholesalers, however customers should bear freight. We DO NOT offer free samples to end users.

A:

  • 1. Email us the model, brand and quantity,shipping way of bearings and we will quote our best price for you;
  • 2. Proforma Invoice made and sent to you as the price agreed by both parts;
  • 3. Deposit Payment after confirming the PI and we arrange production;
  • 4. Balance paid before shipment or after copy of Bill of Loading.
