RBC KP12AFS464 Aerospace Bearings

RBC BEARINGS
KP12AFS464
RBC KP12AFS464 ;  Bearings/Deep groove ball bearings
Single Row Ball Bearing;  3/4" Bore;  1-5/8" Outside Diameter;  3/8" Outer Race Width;  2 Seals;  Non Precision;  No Filling Slot;  No Snap Ring;  C0-Medium Internal Clearance
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Contact with Sales
Packaging Details: SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS
Delivery Time: 5-7 Days After payment
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 100000pcs/month

Product Description


Product Name     RBC Airframe Bearing - KP A Series
Description     KP12AFS464 - RBC Airframe Bearing - KP A Series - 0.75" Bore, 1.625" OD, 0.437" Width
Type     Airframe Control Radial Ball Bearing, Single Row, Sealed, Medium Duty, Cadmium Plated
Style2     Ball Bearing
Inch/Metric     Inch
Inner Diameter     0.75"
Outer Diameter     1.625"
Width     0.437"
Dynamic Capacity     8790 lbf
Inner Ring Width     0.437"
Outer Ring Width     0.375"
Bearing Material     52100 Bearing Quality Steel
Ring Material     52100 Bearing Quality Steel
Finish     Cadmium
Enclosure     Double Sealed
Cage Material     No Cage
Fillet Radius     0.032"
Series     RBC®
Bore Size (in)     0.75
Bore Size (mm)     19.05
Dynamic Load Rating (lbf)     8790
Dynamic Load Rating (N)     39100
Industry Standards/Certifications     SAE-AS27641
Inside Ring Width (in)     0.437
Inside Ring Width (mm)     11.1
Item Name     RBC Airframe Bearing - KP A Series
Material     52100 Bearing Quality Steel
Outside Diameter (in)     1.63
Outside Diameter (mm)     41.28
Outside Ring Width (in)     0.375
Outside Ring Width (mm)     9.53
Static Load Rating (lbf)     8790
Static Load Rating (N)     39100
Weight (lb)     0.13
Bore Shape     Round
Speed (Max) (rpm)     500
Total Width (in)     0.437
Total Width (mm)     11.1
Weight (kg)     0.059
Clearance     C0
Filling Slot     Single Row Non-Fill Slot
Include Snap Ring     No
Outside Ring Shape     Straight

Suzhou DSN Bearings Limited Advantages:

Suzhou DSN Bearings Limited. We have deal with the bearing import and export business more than 20 years.

The company sells NHBB bearings,KAYDON bearings,RBC bearings,INA bearings,MCGILL bearings,RBC bearings,NTN bearings,IKO bearings,KOYO bearings,SFERAX bearings,NMB bearings,NACHI bearings,BARDEN bearings,WINKEL bearings,C-FLEX bearings and other Europe and the United States High precision bearing products.

The main brands are as follows:German brands: MYONIC, GMN, GRW, FAG INA STIEBER NADELLA BARDEN STAR,American brand: NHBB KAYDON RBC MCGILL MRC C-FLEX BARDENJapanese brand: NSK NTN NACHI IJK NMB EZO IKO THK ASAHI KOYO FYHEuropean brand: SKF SNFA RHP SNR ADR RBF ZKL NKE WIB COOPER SFERAX and so on.




FAQs

A: We promise to bear the following responsibilities when defective products were found:

  • 1. 12 months warranty from the first day of receiving goods;
  • 2. Replacements would be sent with goods of your next order;
  • 3. Refund for defective products if customers require.

A: Yes, we provide ODM&OEM services to worldwide customers, we also customize OEM box and packing as your requirements.

A: MOQ is 10pcs for standardized products; for customized products, MOQ should be negotiated in advance. There is no MOQ for sample orders.

A: The lead time for sample orders is 3-5 days, for bulk orders is 5-15 days.

A: Yes we offer free samples to distributors and wholesalers, however customers should bear freight. We DO NOT offer free samples to end users.

A:

  • 1. Email us the model, brand and quantity,shipping way of bearings and we will quote our best price for you;
  • 2. Proforma Invoice made and sent to you as the price agreed by both parts;
  • 3. Deposit Payment after confirming the PI and we arrange production;
  • 4. Balance paid before shipment or after copy of Bill of Loading.
