RBC Heim Rod End Bearing HM4
HM4 - RBC Heim Rod End Bearing - Male, 4 Piece Metal-to-Metal, 0.2500 inches Bore, .2500-28 Threads
Payment & Shipping Terms
| Minimum Order Quantity: | 1 pcs |
| Price: | Contact with Sales |
| Packaging Details: | SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS |
| Delivery Time: | 5-7 Days After payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000pcs/month |
Product Description
| Product Name | RBC Heim Rod End Bearing - Series HM, Male, 4 Piece - Metal to Metal | ||
| Description | HM4 - RBC Heim Rod End Bearing - Male, 4 Piece Metal-to-Metal, 0.2500 inches Bore, .2500-28 Threads | ||
| Type | Male Spherical Plain Rod End, Precision Series | ||
| Style2 | Four Piece - Metal to Metal | ||
| Inch/Metric | Inch | ||
| Inner Diameter | 0.25" | ||
| Outer Diameter | 0.750" | ||
| Width | 0.375" | ||
| Thread Type | UNF-3A | ||
| Inner Ring Width | 0.375" | ||
| Outer Ring Width | 0.281" | ||
| Tilt Angle | 8º | ||
| Sphere Diameter | 0.515" | ||
| Length To Center of Ball | 1.562" | ||
| Bearing Material | 52100 Bearing Quality Steel | ||
| Finish | Steel | ||
| Operating Temperature | Less Than 250 ºF | ||
| Enclosure | Open | ||
| Housing Material | Carbon Steel | ||
| Race Material | Brass | ||
| Series | Heim® | ||
| Thread Direction | Right-Handed Thread | ||
| Thread Gender | Male (Outer) Thread | ||
| Bore Size (in) | 0.25 | ||
| Bore Size (mm) | 6.00 | ||
| Inside Ring Width (in) | 0.375 | ||
| Inside Ring Width (mm) | 10 | ||
| Item Name | RBC Heim Rod End Bearing - Series HM, Male, 4 Piece - Metal to Metal | ||
| Lubrication Type | Non-Lubricatable | ||
| Misalignment Angle º | 8 | ||
| Operating Temperature (Max) ºC | 121.1 | ||
| Operating Temperature (Max) ºF | 250 | ||
| Performance | Precision | ||
| Static Load Rating (lbf) | 1700 | ||
| Static Load Rating (N) | 7562 | ||
| Weight (lb) | 0.05 | ||
| Weight (kg) | 0.02 | ||
| Total Height (in) | 1.937 | ||
| Total Height (mm) | 49 | ||
| Bearing Type | 4 Piece-Metal-to-Metal | ||
| Thread Length (in) | 1.000 | ||
| Thread Size | .2500-28 | ||
| Center Line Length (in) | 1.562 | ||
| Ball Diameter (in) | 0.515 | ||
| Ball Diameter (mm) | 13 | ||
| Shaft Height (mm) | 40 | ||
| Head Width (mm) | 7 | ||
| Ball Material | 52100 Alloy Steel | ||
| Head Diameter (in) | 0.750 | ||
| Head Diameter (mm) | 19 | ||
| Insert Material | Brass | ||
| Shaft Height (in) | 1.562 | ||
| Thread Length (mm) | 25 | ||
| Head Width (in) | 0.281 | ||
| Thread Handedness | Right-Handed | ||
