RBC 12NBC1822YZP Aerospace Bearings MS24461-12G
12NBC1822YZP
RBC BEARINGS 12NBC1822YZP
Needle Roller Bearing; Single Row; 3/4" Bore; 1-3/8" Outside Diameter; 1-1/8" Width; Open; Complete with Outer and Inner Ring; Steel Cage; Spherical Outer Race; Retaining Washer; Airframe; Housing Ring; Non Separable; Self Aligning
Payment & Shipping Terms
| Minimum Order Quantity: | 1 pcs |
| Price: | Contact with Sales |
| Packaging Details: | SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS |
| Delivery Time: | 5-7 Days After payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000pcs/month |
Product Description
| Product Name | RBC Airframe Bearing - NBC Series / SAE AS24461 | ||
| Description | 12NBC1822YZP - RBC Airframe Bearing - NBC Series - 0.7500" Bore x 1.3750" OD x 1.125" Width | ||
| Type | Airframe Needle Roller Bearing, Single Row | ||
| Style | Needle Roller | ||
| Inch/Metric | Inch | ||
| Inner Diameter | 0.7500" | ||
| Outer Diameter | 1.3750" | ||
| Width | 1.125" | ||
| Inner Ring Width | 1.125" | ||
| Outer Ring Width | 1.125" | ||
| Bearing Material | 52100 Bearing Quality Steel | ||
| Finish | Cadmium | ||
| Operating Temperature | 0 to 250 ºF | ||
| Enclosure | Open | ||
| Fillet Radius | 0.032" | ||
| Series | RBC® | ||
| Bore Size (in) | 0.75 | ||
| Bore Size (mm) | 19.05 | ||
| Dynamic Load Rating (lbf) | 23900 | ||
| Dynamic Load Rating (N) | 106312.458 | ||
| Item Name | RBC Airframe Bearing - NBC Series / SAE AS24461 | ||
| Lubrication Type | Hole On Outer Ring | ||
| Material | 52100 Bearing Quality Steel | ||
| Operating Temperature (Max) ºC | 121.1 | ||
| Operating Temperature (Max) ºF | 250 | ||
| Operating Temperature (Min) ºC | -17.8 | ||
| Outside Diameter (in) | 1.38 | ||
| Outside Diameter (mm) | 34.93 | ||
| Static Load Rating (lbf) | 23900 | ||
| Static Load Rating (N) | 106312.458 | ||
| Weight (lb) | 0.336 | ||
| Bore Shape | Round | ||
| Fillet Radius/Chamfer (in) | 0.032 | ||
| Fillet Radius/Chamfer (mm) | 0.8128 | ||
| Precision Rating | Not Rated | ||
| Speed (Max) (rpm) | 100 | ||
| Total Width (in) | 1.125 | ||
| Total Width (mm) | 28.575 | ||
| Weight (kg) | 0.152544 | ||
