FAG B71907-C-2RSD-T-P4S-UL spindle bearing

FAG B71907-C-2RSD-T-P4S-UL spindle bearing
Payment & Shipping Terms

Minimum Order Quantity:	1 pcs
Price:	Contact with Sales
Packaging Details:	SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS
Delivery Time:	5-7 Days After payment
Payment Terms:	L/C, T/T, Western Union, Paypal
Supply Ability:	100000pcs/month

Request a Quote

Product Description

Main Dimensions & Performance Data

d	35 mm	Bore diameter
D	55 mm	Outside diameter
B	10 mm	Width
C_r	12.100 N	Basic dynamic load rating, radial
C_0r	6.800 N	Basic static load rating, radial
C_ur	720 N	Fatigue load limit, radial
n_{G Grease}	26.000 1/min	Limiting speed for grease lubrication
≈m	75,8 g	Weight

Mounting dimensions

d_a	40 mm	Diameter shaft shoulder
d_a	h12	Diameter shaft shoulder clearance
D_a	51,5 mm	Shoulder diameter outer ring
D_a	H12	Shoulder diameter outer ring clearance
r_{a max}	0,6 mm	Maximum recess radius
r_{a1 max}	0,15 mm	Maximum recess radius
a	11,1 mm	Distance between the apexes of the pressure cones

Dimensions

r_min	0,6 mm	Minimum chamfer dimension
r_{1 min}	0,6 mm	Minimum chamfer dimension
α	15 °	Contact angle

Temperature range

T_min	-30 °C	Operating temperature min.
T_max	80 °C	Operating temperature max.

Additional information

F_{V L}	50 N	Preload force light
F_{V M}	185 N	Preload force medium
F_{V H}	384 N	Preload force heavy
K_{aE L}	155 N	Lift-off force light
K_{aE M}	619 N	Lift-off force medium
K_{aE H}	1.377 N	Lift-off force heavy
c_{a L}	34 N/µm	Axial rigidity light
c_{a M}	60 N/µm	Axial rigidity medium
c_{a H}	88 N/µm	Axial rigidity heavy

Your current product variant

Contact angle	C	Contact angle 15°
Lubricant	Standard
Sealing	2RSD	non-contact sealed on both sides and greased “for life”
Outer shape	Standard
Cage	T	Laminated fabric cage
Tolerance class	P4S	tolerance class P4S, FAG standard better than P4 to DIN 620
Arrangement bearing set	U	Single bearing
