FAG 3210-BD-XL-2Z-TVH main shaft bearing
3210-BD-XL-2Z-TVH FAG
Inner (d) MM
50,00
Outer (D) MM
90,00
Width (B) MM
30,20
Inner (d) Inch
1.9685
Outer (D) Inch
3.5433
Width (B) Inch
1.1890
Weight (kg)
0.677
Payment & Shipping Terms
| Minimum Order Quantity: | 1 pcs |
| Price: | Contact with Sales |
| Packaging Details: | SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS |
| Delivery Time: | 5-7 Days After payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000pcs/month |
Product Description
- BoreC - Cylindrical Bore
- SealZZ/2Z - Steel Seal on Two Sides
- Cage TypeP - Plastic Molded Cage
- External ModificationNo External Modification
- Radial Internal PlayCn Normal Internal Play
- PrecisionStandard Precision
- LubricationStandard Lubrication
- Heat StabilizationNo Heat Stabilization - Temperatures up to 120 °C
- Split Inner ring / Outer ringStandard
Data from Schaeffler (medias)
- Width (b) mm30,20
- Radial Static Load Rating C0r (N)44000
- Radial Dynamic Load Rating Cr (N)53000
- Basic static load rating, radial (C 0r)"44000.0000"
- Limiting speed (n G)"5900.0000"
- Reference speed (n ϑr)"7600.0000"
- Medias descriptionAngular contact ball bearings 32..-BD-2Z, main dimensions to DIN 628-3, double row, gap seals on both sides, contact angle a = 30°
Suffix description
- BDModified Internal Construction, Contact Angle α=30°, Without Filling Slot
- XLX-Life
- 2ZShields At Both Sides Of The Bearing
- TVHMoulded Polyamide Cage Snap-Type, Rolling Element Riding
| Bearing No. | d | D | B |
| mm | mm | mm | |
| 3202-BD-XL-2HRS | 15 | 35 | 15.9 |
| 3202-BD-XL-2HRS-TVH | 15 | 35 | 15.9 |
| 3203-BD-XL-2HRS | 17 | 40 | 17.5 |
| 3203-BD-XL-2HRS-TVH | 17 | 40 | 17.5 |
| 3204-BD-XL-2HRS | 20 | 47 | 20.6 |
| 3204-BD-XL-2HRS-TVH | 20 | 47 | 20.6 |
| 3205-BD-XL-2HRS | 25 | 52 | 20.6 |
| 3205-BD-XL-2HRS-TVH | 25 | 52 | 20.6 |
| 3206-BD-XL-2HRS | 30 | 62 | 23.8 |
| 3206-BD-XL-2HRS-TVH | 30 | 62 | 23.8 |
| 3207-BD-XL-2HRS | 35 | 72 | 27 |
| 3207-BD-XL-2HRS-TVH | 35 | 72 | 27 |
| 3208-BD-XL-2HRS | 40 | 80 | 30.2 |
| 3208-BD-XL-2HRS-TVH | 40 | 80 | 30.2 |
| 3209-BD-XL-2HRS | 45 | 85 | 30.2 |
| 3209-BD-XL-2HRS-TVH | 45 | 85 | 30.2 |
| 3210-BD-XL-2HRS | 50 | 90 | 30.2 |
| 3210-BD-XL-2HRS-TVH | 50 | 90 | 30.2 |
| 3211-BD-XL-2HRS | 55 | 100 | 33.3 |
| 3211-BD-XL-2HRS-TVH | 55 | 100 | 33.3 |
| 3212-BD-XL-2HRS | 60 | 110 | 36.5 |
| 3212-BD-XL-2HRS-TVH | 60 | 110 | 36.5 |
| 3213-BD-XL-2HRS | 65 | 120 | 38.1 |
| 3213-BD-XL-2HRS-TVH | 65 | 120 | 38.1 |
| 3302-BD-XL-2HRS-TVH | 15 | 42 | 19 |
| 3303-BD-XL-2HRS-TVH | 17 | 47 | 22.2 |
| 3304-BD-XL-2HRS | 20 | 52 | 22.2 |
| 3304-BD-XL-2HRS-TVH | 20 | 52 | 22.2 |
| 3305-BD-XL-2HRS | 25 | 62 | 25.4 |
| 3305-BD-XL-2HRS-TVH | 25 | 62 | 25.4 |
| 3306-BD-XL-2HRS | 30 | 72 | 30.2 |
| 3306-BD-XL-2HRS-TVH | 30 | 72 | 30.2 |
| 3307-BD-XL-2HRS | 35 | 80 | 34.9 |
| 3307-BD-XL-2HRS-TVH | 35 | 80 | 34.9 |
| 3308-BD-XL-2HRS | 40 | 90 | 36.5 |
| 3308-BD-XL-2HRS-TVH | 40 | 90 | 36.5 |
| 3309-BD-XL-2HRS | 45 | 100 | 39.7 |
| 3309-BD-XL-2HRS-TVH | 45 | 100 | 39.7 |
| 3310-BD-XL-2HRS | 50 | 110 | 44.4 |
| 3310-BD-XL-2HRS-TVH | 50 | 110 | 44.4 |
| 3311-BD-XL-2HRS | 55 | 120 | 49.2 |
| 3311-BD-XL-2HRS-TVH | 55 | 120 | 49.2 |
| 3316-BD-XL-2HRS-TVH | 80 | 170 | 68.3 |
| 3314 | 70 | 150 | 63.5 |
| 3315 | 75 | 160 | 68.3 |
| 3316 | 80 | 170 | 68.3 |
| 3317-M | 85 | 180 | 73 |
| 3318 | 90 | 190 | 73 |
| 3319-M | 95 | 200 | 77.8 |
| 3320-M | 100 | 215 | 82.6 |
| 3322-M | 110 | 240 | 92.1 |
| 3217 | 85 | 150 | 49.2 |
| 3218 | 90 | 160 | 52.4 |
| 3219-M | 95 | 170 | 55.6 |
| 3220 | 100 | 180 | 60.3 |
| 3221-M | 105 | 190 | 65.1 |
| 3222-M | 110 | 200 | 69.8 |
