FAG 3210-BD-XL-2HRS-TVH main shaft bearing
Inner (d) MM
50,00
Outer (D) MM
90,00
Width (B) MM
30,20
Inner (d) Inch
1.9685
Outer (D) Inch
3.5433
Width (B) Inch
1.1890
Weight (kg)
0.673
Payment & Shipping Terms
| Minimum Order Quantity: | 1 pcs |
| Price: | Contact with Sales |
| Packaging Details: | SINGLE BOX PACKING - CARTON BOX PACKING - PALLETS |
| Delivery Time: | 5-7 Days After payment |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000pcs/month |
Product Description
- BoreC - Cylindrical Bore
- Seal2RH - High Speed Low Friction Seal on Two Sides
- Cage TypeP - Plastic Molded Cage
- External ModificationNo External Modification
- Radial Internal PlayCn Normal Internal Play
- PrecisionStandard Precision
- LubricationStandard Lubrication
- Heat StabilizationNo Heat Stabilization - Temperatures up to 120 °C
- Split Inner ring / Outer ringStandard
Data from Schaeffler (medias)
- Width (b) mm30,20
- Radial Static Load Rating C0r (N)44000
- Radial Dynamic Load Rating Cr (N)53000
- Basic static load rating, radial (C 0r)"44000.0000"
- Limiting speed (n G)"5900.0000"
- Medias descriptionAngular contact ball bearings 32..-BD-2HRS, main dimensions to DIN 628-3, double row, lip seals on both sides, contact angle a = 30°
Suffix description
- BDModified Internal Construction, Contact Angle α=30°, Without Filling Slot
- XLX-Life
- 2HRSLip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal
- TVHMoulded Polyamide Cage Snap-Type, Rolling Element Riding
| Bearing No. | d | D | B |
| mm | mm | mm | |
| 3202-BD-XL-2HRS | 15 | 35 | 15.9 |
| 3202-BD-XL-2HRS-TVH | 15 | 35 | 15.9 |
| 3203-BD-XL-2HRS | 17 | 40 | 17.5 |
| 3203-BD-XL-2HRS-TVH | 17 | 40 | 17.5 |
| 3204-BD-XL-2HRS | 20 | 47 | 20.6 |
| 3204-BD-XL-2HRS-TVH | 20 | 47 | 20.6 |
| 3205-BD-XL-2HRS | 25 | 52 | 20.6 |
| 3205-BD-XL-2HRS-TVH | 25 | 52 | 20.6 |
| 3206-BD-XL-2HRS | 30 | 62 | 23.8 |
| 3206-BD-XL-2HRS-TVH | 30 | 62 | 23.8 |
| 3207-BD-XL-2HRS | 35 | 72 | 27 |
| 3207-BD-XL-2HRS-TVH | 35 | 72 | 27 |
| 3208-BD-XL-2HRS | 40 | 80 | 30.2 |
| 3208-BD-XL-2HRS-TVH | 40 | 80 | 30.2 |
| 3209-BD-XL-2HRS | 45 | 85 | 30.2 |
| 3209-BD-XL-2HRS-TVH | 45 | 85 | 30.2 |
| 3210-BD-XL-2HRS | 50 | 90 | 30.2 |
| 3210-BD-XL-2HRS-TVH | 50 | 90 | 30.2 |
| 3211-BD-XL-2HRS | 55 | 100 | 33.3 |
| 3211-BD-XL-2HRS-TVH | 55 | 100 | 33.3 |
| 3212-BD-XL-2HRS | 60 | 110 | 36.5 |
| 3212-BD-XL-2HRS-TVH | 60 | 110 | 36.5 |
| 3213-BD-XL-2HRS | 65 | 120 | 38.1 |
| 3213-BD-XL-2HRS-TVH | 65 | 120 | 38.1 |
| 3302-BD-XL-2HRS-TVH | 15 | 42 | 19 |
| 3303-BD-XL-2HRS-TVH | 17 | 47 | 22.2 |
| 3304-BD-XL-2HRS | 20 | 52 | 22.2 |
| 3304-BD-XL-2HRS-TVH | 20 | 52 | 22.2 |
| 3305-BD-XL-2HRS | 25 | 62 | 25.4 |
| 3305-BD-XL-2HRS-TVH | 25 | 62 | 25.4 |
| 3306-BD-XL-2HRS | 30 | 72 | 30.2 |
| 3306-BD-XL-2HRS-TVH | 30 | 72 | 30.2 |
| 3307-BD-XL-2HRS | 35 | 80 | 34.9 |
| 3307-BD-XL-2HRS-TVH | 35 | 80 | 34.9 |
| 3308-BD-XL-2HRS | 40 | 90 | 36.5 |
| 3308-BD-XL-2HRS-TVH | 40 | 90 | 36.5 |
| 3309-BD-XL-2HRS | 45 | 100 | 39.7 |
| 3309-BD-XL-2HRS-TVH | 45 | 100 | 39.7 |
| 3310-BD-XL-2HRS | 50 | 110 | 44.4 |
| 3310-BD-XL-2HRS-TVH | 50 | 110 | 44.4 |
| 3311-BD-XL-2HRS | 55 | 120 | 49.2 |
| 3311-BD-XL-2HRS-TVH | 55 | 120 | 49.2 |
| 3316-BD-XL-2HRS-TVH | 80 | 170 | 68.3 |
| 3314 | 70 | 150 | 63.5 |
| 3315 | 75 | 160 | 68.3 |
| 3316 | 80 | 170 | 68.3 |
| 3317-M | 85 | 180 | 73 |
| 3318 | 90 | 190 | 73 |
| 3319-M | 95 | 200 | 77.8 |
| 3320-M | 100 | 215 | 82.6 |
| 3322-M | 110 | 240 | 92.1 |
| 3217 | 85 | 150 | 49.2 |
| 3218 | 90 | 160 | 52.4 |
| 3219-M | 95 | 170 | 55.6 |
| 3220 | 100 | 180 | 60.3 |
| 3221-M | 105 | 190 | 65.1 |
| 3222-M | 110 | 200 | 69.8 |
